Garmin Garmin ECHOMAP UHD2 9" Chartplotter, 95sv with GT56UHD-TM Transducer and Garmin Navionics+ Australia & New Zealand Mapping

Product Code: GAR-010-02690-20

The echoMAP UHD2 95sv chartplotter with 9" screen is preloaded with highly detailed Garmin Navionics+ Australia and New Zealand data and includes Quickdraw Contours map drawing software.

$2,199.00 $1,799.00 In Stock Out of Stock

All prices include GST

Find your closest store to pick-up or deliver your order from
The estimated delivery is 3-5 business days

Shipping Calculator

Share:

Description Specifications Downloads

The echoMAP UHD2 95sv chartplotter with 9" screen is preloaded with highly detailed Garmin Navionics+ Australia and New Zealand data and includes Quickdraw Contours map drawing software.

The echoMAP UHD2 95sv combo features a 9" keyed-assist touchscreen display and is supplied with a high performance GT56UHD transom mount transducer for high-wide CHIRP, Ultra High-Definition ClearV� and SideV� scanning sonar for improved detail and distinguished targets through high contrast vivid colour palettes.

The UHD2 95sv has built-in Wi-Fi to pair with the free ActiveCaptain app for access to OneChart to purchase and download new charts, smart notifications, software updates, Garmin QuickDraw Community data and more. Includes built in waterproof data slot for single microSD card to a maximum of 32GB.

The echoMAP UHD2 95sv wirelessly connects to your Garmin Force trolling motor to create and follow routes including the ability to navigate to waypoints, control speed, check battery life and more!

The UHD2 95sv supports the Panoptix LiveScope System and NMEA 2000 network. Is supplied with a quick-release bail mount for easy removal support.

General

  • Dimension 10.4″ x 6.5″ x 3.2″ (26.4 x 16.6 x 8 cm)

  • Weight 2.9 lbs (1.3 kg)

  • Water rating IPX7

  • Touchscreen Yes

  • Display Type WSVGA, TN

  • Display Size 7.8″ x 4.5″, 9″ (19.8 x 11.5 cm, 22.9 cm)

  • Display Resolution 1024 x 600 pixels

  • Mounting Options Bail or flush

  • Input Touchscreen with Keyed Assist

Maps & Memory

  • Accepts Data Cards 1 microSDâ„¢ card; 32 GB maximum size

  • Waypoints 5,000

  • Track points 50,000

  • Tracks 50 saved tracks

  • Navigation Routes 100

Sensors

  • GPS Yes

  • GLONASS Yes

  • Galileo Yes

  • BeiDou Yes

  • Has built-in receiver Yes

  • Receiver 10 Hz

  • NMEA 2000 Compatible Yes

  • Supports WAAS Yes

  • Supports multi-band, multi-constellation GPS Yes

Built-in maps

  • Built-in Auto Guidance+ Yes (downloadable via ActiveCaptain app)

  • Garmin Navionics+ Inland & Coastal Yes (see Additional)

  • Garmin Navionics+â„¢ (Coastal) Yes (see Additional)

  • Garmin Navionics+ (Inland) Yes (see Additional)

  • Tide tables Yes (see Additional)

Optional map support

  • BlueChart g3 Yes

  • BlueChart g3 Vision Yes

  • LakeVü g3 Yes

  • LakeVü g3 Ultra Yes

  • Garmin Navionics+â„¢ Yes

  • Garmin Navionics Vision+â„¢ Yes

  • TOPO 100K Yes

  • Standard Mapping Yes

  • Garmin Quickdraw Contours Yes

Chartplotter Features

  • AIS Yes

  • DSC Yes

  • Supports Fusion-Linkâ„¢ compatible radios Yes

  • ActiveCaptain Mobile Planning Compatible yes

  • Sailing Features Yes

  • Electrical features

  • POWER INPUT 9 to 18 Vdc

  • Typical current draw at 12 Vdc 1.72 A

  • Maximum current draw at 12 Vdc 3.5 A

  • Maximum power usage at 10 Vdc 20.7 W

Sonar Features

  • Displays sonar Yes

  • Power output 500 W

  • Traditional sonar (dual frequency/beam) Built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)

  • ClearVü Built-in 260/455/800/1000/1200 kHz

  • SideVü Built-in 260/455/800/1000/1200 kHz

  • Panoptixâ„¢ sonar Yes

  • LiveScope Yes

Connections

  • NMEA 2000® ports yes

  • Garmin Marine Network Ports 1

  • 12-pin transducer ports 1

  • Bluetooth® pairing Yes

  • ANT® (Connectivity) Yes

  • Garmin Wi-Fi network (local connection) Yes

Additional

  • Garmin Navionics+ (inland and coastal): 95sv Canada, Australia and New Zealand

  • Garmin Navionics+ (coastal): 94sv U.S. coastal, 95sv UK/Ireland

  • Garmin Navionics+ (inland): 93sv U.S. lakes

  • Tide tables: 93sv, 94sv, 95sv

  • Weight: 1.0000
  • Height: 0
  • Width: 0
